Preserve Roof Aesthetics: Modern solar tiles and low-profile pv mounting systems blend seamlessly with traditional tile designs.

Step-By-Step Installation Process
Step 1: Plan And Design The System
Choose the appropriate solar roof hooks/solar L feet according to the type of your tiled roof, because we have aluminum roof hooks and steel roof hooks and aluminum L feet, must choose the best roof hooks to install.
Step 2: Install Mounting Hardware
Rail-Based System:
Secure aluminum solar rails to the roof using stainless steel solar roof hooks/solar L feet.
Attach rails to L-feet/solar mounting hooks, ensuring alignment and stability.
Use solar clamps to fix panels to solar mounting rails, leaving gaps for thermal expansion.
Railless System:
Position panels directly on tiles using specialized solar brackets.
Secure panels with tamper-proof screws, avoiding tile cracks.
Solar Tiles:
Replace traditional tiles with solar tiles, connecting them in series.
Integrate with hidden wiring to maintain a clean roofline.
Step 4: Electrical Integration
Wiring: Connect panels via MC4 connectors, routing cables through roof penetrations sealed with flashing.
Inverter Installation: Place the inverter near the main electrical panel, ensuring proper ventilation.
Battery Backup (Optional): Install lithium-ion batteries to store excess energy.
Step 5: Final Inspections And Activation
Structural Check: Verify all solar mounts are secure and panels are evenly spaced.
Electrical Testing: Use a multimeter to confirm voltage and all the solar mounting system functionality.
Utility Approval: Coordinate with the utility company to activate net metering and grid connection.
